Driver Operated terminal (PC System)

This is a Stainless Steel Driver Operated Terminal fitted with a  10.1” touchscreen PC, designed for use with our Weighbridge Software or any Windows based Software. It is perfect for self-service weighbridge management. Equipped with thermal printer and RFID reader.

Features

  • Satin STAINLESS steel electrical panel board, equipped with electromechanics and power supply unit for integrated devices.
  • Protection visor for outdoor use, from sun and rain.
  • 10.1″ high-brightness resistive touchscreen display (1280x800px), suitable for use with gloves and water/condensation.
  • Intel 64bit Quad Core Processor, up to 1.92GHz.
  • Intel GEN 8 HD 400 Graphics Processor Unit (GPU).
  • Windows 10 operating system pre-installed.
  • 4GB DDR3L RAM.
  • Fast data storage 64GB eMMC.
  • Built-in RTC (for date/time, bios, etc).
  • Double aeration grille and built-in fan.
  • Internal heating unit with thermostat.
  • RFID proximity reader, with reading distance up to 30mm.
  • Thermal printer with paper-cutter. Printing speed >150mm/sec., 200 dpi resolution, 24/40 columns, 80mm paper width.
  • 110-240 Vac power supply unit.

Interfaces

  • 3 available 2.0 USB ports inside
  • 1 ETHERNET port (1x Gbit)
  • 1 3.0 OTG USB inside
